DucoBox local Api-Key generator

The Duco Installation App authenticates to the DucoBox Connectivity Board's local API with an Api-Key HTTP header. That key is computed on the device from two values the box exposes — there is no secret handshake. Enter those two values below to reproduce the key.

HTTPS only. The generated key is only accepted by the box over an https:// connection. Requests over plain http:// are rejected, so point your client at https://<box-ip>/ (the board uses a self-signed certificate).
From GET /info → General.Board.SerialBoardBox. Shown as "SerialBoard" for the BOX node.
From GET /info → General.Lan.Mac. Must be lower-case (with colons) for the key to be accepted — this page lower-cases it for you.
Uses the calendar day in your local time zone; defaults to today.

What the key unlocks

On the board's own web interface you paste this key into the small text box in the top-left corner (next to the DUCO logo). Without it you see only a limited, read-only view. Once a valid key is entered, the interface reveals many more values and enables write actions, such as:

DucoBox web interface Node Info, with the Api-Key text box highlighted in the top-left
The board's web UI. The Api-Key goes in the text box top-left (under the DUCO logo). After entering it, all the tabs (Node/Box/Zone config & actions, Programs, LAN, Firmware) become usable. Serial numbers in this screenshot have been randomised.

How it works (short version)

  1. Start from a fixed 64-character seed baked into the APK.
  2. Mix the MAC address into positions 0…len-1 and the board serial into positions 32…, using a per-character folding function that maps every result back into [0-9 A-Z a-z].
  3. Shuffle blocks of four characters based on the bits of the current day number (localEpochSeconds / 86400) — this makes the key rotate daily.

The box runs the identical algorithm to validate. It is security-through-obscurity, not real cryptography: the seed and the algorithm are both recoverable from the app. Full details and the decompiled bytecode are in the algorithm write-up.

Prefer the command line? The repository ships duco_apikey.py (algorithm only) and duco_apikey_fetch.py (fetches the serial + MAC from the box automatically and computes the key).

Disclaimer

Independent reverse-engineering of the publicly distributed Duco Installation App, for interoperability and research. Not affiliated with or endorsed by DUCO. Use only on equipment you own or are authorised to access. No warranty.
